NAO BlueSpot
NAO® Bluespot v5 is designed to provide stable, consistent, and calibrated Bluetooth Low Energy transmission, ensuring accurate and reliable location tracking to within one meter. This accuracy enables real-time tracking of assets, equipment, teams, or visitors, even in complex environments with high radio density (airport terminals, hospital buildings, industrial sites).
The stability of the signal ensures continuity of service, which is essential for critical uses, without position drift or performance degradation over time.
Features and integration
The NAO® BlueSpot V5 is a programmable BLE beacon capable of transmitting different frame formats: iBeacon™, Eddystone™, NAO® proprietary frame, or Eddystone-TLM. With its adjustable transmission power and configurable range of up to 100 meters, it can be adapted to any scenario: indoor positioning, traffic counting, mobile navigation, or asset tracking.
The device connects directly to the NAO® Track RTLS engine via BLE access points or NAO® BlueListener gateways, which capture and relay signals to the NAO® Cloud. Integration is instantaneous in Cisco Spaces, Aruba, Extreme Networks, or Fortinet environments, enabling rapid deployment on existing Wi-Fi networks.
The beacon can also carry environmental sensors (temperature, battery, movement) and transmit telemetry data to enrich analyses via NAO® Analytics. Configuration and maintenance are easily performed remotely using NAO® Logger or via a BLE provisioning mobile application.
Security, performance, and durability
The NAO® BlueSpot V5 is designed to offer exceptional battery life, up to 10 years of operation depending on the emission profile. Its robust construction (IP65) makes it suitable for indoor and outdoor use, even in demanding industrial or logistics environments.
All BLE communications are encrypted according to Bluetooth 5.2 security protocols and are GDPR-compliant when used with the NAO® Cloud. Firmware updates are performed Over-The-Air (OTA), ensuring the longevity and security of the infrastructure without the need for on-site intervention.
Benefits and use cases
Accurate and stable BLE positioning
NAO® Bluespot v5 is designed to provide stable, consistent, and calibrated Bluetooth Low Energy transmission, ensuring accurate and reliable location tracking to within one meter.
This accuracy enables real-time tracking of assets, equipment, teams, or visitors, even in complex environments with high radio density (airport terminals, hospital buildings, industrial sites).
The stability of the signal ensures continuity of service, which is essential for critical uses, without position drift or performance degradation over time.
Compatibility with major network infrastructures
Designed to integrate easily with existing infrastructures, NAO® Bluespot v5 is fully compatible with the major network providers on the market (Cisco, Aruba, Fortinet, etc.).
This flexibility allows for rapid deployment without the need to overhaul IT architecture and facilitates the gradual expansion of RTLS projects across multiple buildings or sites, limiting costs and implementation times.
Remote management and maintenance via NAO Cloud
Thanks to its native integration with NAO® Cloud, NAO® Bluespot v5 can be configured, monitored, and updated remotely.
Technical teams can adjust settings, schedule updates, or monitor the status of beacons without physical intervention on site. This approach significantly reduces maintenance operations, limits service interruptions, and improves operational continuity.
Low energy consumption and long battery life
NAO® Bluespot v5 has been designed for minimal energy consumption, enabling extended battery life and reducing the need for battery replacements.
This durability is essential for large-scale deployments, where equipment reliability and limited field interventions are major challenges. It also contributes to a more responsible and sustainable approach to RTLS projects.
Full integration with the NAO ecosystem
Fully integrated into the Pole Star ecosystem, NAO® Bluespot v5 works seamlessly with NAO® Track, NAO® Mobile, and NAO® Analytics. This interoperability guarantees a complete value chain, from field signal collection to data analysis, operational visualization, and application integration. It enables rapid deployment of advanced use cases and full exploitation of location data.
